* Excellent clamping capability
* Low zener impedance
* Fast response time: Typically less than 1.0ps from 0 volt to BV Min.
* Typical IR less than 1 µA above 10V
* High temperature soldering guaranteed: 260°c / 10 seconds/.375"(9.5mm) lead length, 5 lbs(2.3kg) tension
| Part Number | VRWM | VBR | VBR | IT | IR | VC | IPP | PPK | Package | Download | |
| Max. | Min. | Max. | Max. | ||||||||
| Uni | Bi | V | V | V | mA | μA | V | A | W | ||
| P4KE6.8A | P4KE6.8CA | 5.8 | 6.45 | 7.14 | 10 | 1000 | 10.50 | 40.00 | 400 | DO-41 | |
| P4KE7.5A | P4KE7.5CA | 6.4 | 7.13 | 7.88 | 10 | 500 | 11.30 | 37.00 | 400 | DO-41 | |
| P4KE8.2A | P4KE8.2CA | 7.0 | 7.79 | 8.61 | 10 | 200 | 12.10 | 35.00 | 400 | DO-41 | |
| P4KE9.1A | P4KE9.1CA | 7.8 | 8.65 | 9.50 | 1 | 50 | 13.40 | 31.00 | 400 | DO-41 | |
| P4KE10A | P4KE10CA | 8.6 | 9.50 | 10.50 | 1 | 10 | 14.50 | 29.00 | 400 | DO-41 | |
| P4KE11A | P4KE11CA | 9.4 | 10.50 | 11.60 | 1 | 5 | 15.60 | 27.00 | 400 | DO-41 | |
| P4KE12A | P4KE12CA | 10.2 | 11.40 | 12.60 | 1 | 5 | 16.70 | 25.00 | 400 | DO-41 | |
| P4KE13A | P4KE13CA | 11.1 | 12.40 | 13.70 | 1 | 5 | 18.20 | 23.00 | 400 | DO-41 | |
| P4KE15A | P4KE15CA | 12.8 | 14.30 | 15.80 | 1 | 5 | 21.20 | 20.00 | 400 | DO-41 | |
| P4KE16A | P4KE16CA | 13.6 | 15.20 | 16.80 | 1 | 5 | 22.50 | 19.00 | 400 | DO-41 | |
| P4KE18A | P4KE18CA | 15.3 | 17.10 | 18.90 | 1 | 5 | 25.20 | 17.00 | 400 | DO-41 | |
| P4KE20A | P4KE20CA | 17.1 | 19.00 | 21.00 | 1 | 5 | 27.70 | 15.00 | 400 | DO-41 | |
| P4KE22A | P4KE22CA | 18.8 | 20.90 | 23.10 | 1 | 5 | 30.60 | 14.00 | 400 | DO-41 | |
| P4KE24A | P4KE24CA | 20.5 | 22.80 | 25.20 | 1 | 5 | 33.20 | 13.00 | 400 | DO-41 | |
| P4KE27A | P4KE27CA | 23.1 | 25.70 | 28.40 | 1 | 5 | 37.50 | 11.00 | 400 | DO-41 | |
| P4KE30A | P4KE30CA | 25.6 | 28.50 | 31.50 | 1 | 5 | 41.40 | 10.00 | 400 | DO-41 | |
| P4KE33A | P4KE33CA | 28.2 | 31.40 | 34.70 | 1 | 5 | 45.70 | 9.00 | 400 | DO-41 | |
| P4KE36A | P4KE36CA | 30.8 | 34.20 | 37.80 | 1 | 5 | 49.90 | 8.40 | 400 | DO-41 | |
| P4KE39A | P4KE39CA | 33.3 | 37.10 | 41.00 | 1 | 5 | 53.90 | 7.80 | 400 | DO-41 | |
| P4KE43A | P4KE43CA | 36.8 | 40.90 | 45.20 | 1 | 5 | 59.30 | 7.10 | 400 | DO-41 | |
| P4KE47A | P4KE47CA | 40.2 | 44.70 | 49.40 | 1 | 5 | 64.80 | 6.40 | 400 | DO-41 | |
| P4KE51A | P4KE51CA | 43.6 | 48.50 | 53.60 | 1 | 5 | 70.10 | 6.00 | 400 | DO-41 | |
| P4KE56A | P4KE56CA | 47.8 | 53.20 | 58.80 | 1 | 5 | 77.00 | 5.50 | 400 | DO-41 | |
| P4KE62A | P4KE62CA | 53.0 | 58.90 | 65.10 | 1 | 5 | 85.00 | 5.00 | 400 | DO-41 | |
| P4KE68A | P4KE68CA | 58.1 | 64.60 | 71.40 | 1 | 5 | 92.00 | 4.60 | 400 | DO-41 | |
| P4KE75A | P4KE75CA | 64.1 | 71.30 | 78.80 | 1 | 5 | 103.00 | 4.10 | 400 | DO-41 | |
| P4KE82A | P4KE82CA | 70.1 | 77.90 | 86.10 | 1 | 5 | 113.00 | 3.70 | 400 | DO-41 | |
| P4KE91A | P4KE91CA | 77.8 | 86.50 | 95.50 | 1 | 5 | 125.00 | 3.40 | 400 | DO-41 | |
| P4KE100A | P4KE100CA | 85.5 | 95.00 | 105.00 | 1 | 5 | 137.00 | 3.10 | 400 | DO-41 | |
| P4KE110A | P4KE110CA | 94.0 | 105.00 | 116.00 | 1 | 5 | 152.00 | 2.80 | 400 | DO-41 | |
| P4KE120A | P4KE120CA | 102.0 | 114.00 | 126.00 | 1 | 5 | 165.00 | 2.50 | 400 | DO-41 | |
| P4KE130A | P4KE130CA | 111.0 | 124.00 | 137.00 | 1 | 5 | 179.00 | 2.30 | 400 | DO-41 | |
| P4KE150A | P4KE150CA | 128.0 | 143.00 | 158.00 | 1 | 5 | 207.00 | 2.00 | 400 | DO-41 | |
| P4KE160A | P4KE160CA | 136.0 | 152.00 | 168.00 | 1 | 5 | 219.00 | 1.90 | 400 | DO-41 | |
| P4KE170A | P4KE170CA | 145.0 | 162.00 | 179.00 | 1 | 5 | 234.00 | 1.80 | 400 | DO-41 | |
| P4KE180A | P4KE180CA | 154.0 | 171.00 | 189.00 | 1 | 5 | 246.00 | 1.70 | 400 | DO-41 | |
| P4KE200A | P4KE200CA | 171.0 | 190.00 | 210.00 | 1 | 5 | 274.00 | 1.50 | 400 | DO-41 | |
| P4KE220A | P4KE220CA | 185.0 | 209.00 | 231.00 | 1 | 5 | 328.00 | 1.30 | 400 | DO-41 | |
| P4KE250A | P4KE250CA | 214.0 | 237.00 | 263.00 | 1 | 5 | 344.00 | 1.20 | 400 | DO-41 | |
| P4KE300A | P4KE300CA | 256.0 | 285.00 | 315.00 | 1 | 5 | 414.00 | 1.00 | 400 | DO-41 | |
| P4KE350A | P4KE350CA | 300.0 | 332.00 | 368.00 | 1 | 5 | 482.00 | 0.80 | 400 | DO-41 | |
| P4KE400A | P4KE400CA | 342.0 | 380.00 | 420.00 | 1 | 5 | 548.00 | 0.70 | 400 | DO-41 | |
| P4KE440A | P4KE440CA | 376.0 | 418.00 | 462.00 | 1 | 5 | 600.00 | 0.60 | 400 | DO-41 | |
| SMAJ5.0A | SMAJ5.0CA | 5.0 | 6.40 | 7.30 | 10 | 800 | 9.20 | 43.50 | 400 | SMA/DO-214AC | |
| SMAJ6.0A | SMAJ6.0CA | 6.0 | 6.67 | 7.37 | 10 | 800 | 10.30 | 38.80 | 400 | SMA/DO-214AC | |
| SMAJ6.5A | SMAJ6.5CA | 6.5 | 7.22 | 7.98 | 10 | 500 | 11.20 | 35.70 | 400 | SMA/DO-214AC | |
| SMAJ7.0A | SMAJ7.0CA | 7.0 | 7.78 | 8.60 | 10 | 200 | 12.00 | 33.30 | 400 | SMA/DO-214AC | |
| SMAJ7.5A | SMAJ7.5CA | 7.5 | 8.33 | 8.21 | 1 | 100 | 12.90 | 31.00 | 400 | SMA/DO-214AC | |
| SMAJ8.0A | SMAJ8.0CA | 8.0 | 8.89 | 9.83 | 1 | 50 | 13.60 | 29.40 | 400 | SMA/DO-214AC | |
| SMAJ8.5A | SMAJ8.5CA | 8.5 | 9.44 | 10.40 | 1 | 10 | 14.40 | 27.70 | 400 | SMA/DO-214AC | |
| SMAJ9.0A | SMAJ9.0CA | 9.0 | 10.00 | 11.10 | 1 | 5 | 15.40 | 26.00 | 400 | SMA/DO-214AC | |
| SMAJ10A | SMAJ10CA | 10.0 | 11.10 | 12.30 | 1 | 5 | 17.00 | 23.50 | 400 | SMA/DO-214AC | |
| SMAJ11A | SMAJ11CA | 11.0 | 12.20 | 13.50 | 1 | 5 | 18.20 | 22.00 | 400 | SMA/DO-214AC | |
| SMAJ12A | SMAJ12CA | 12.0 | 13.30 | 14.70 | 1 | 5 | 19.90 | 20.10 | 400 | SMA/DO-214AC | |
| SMAJ13A | SMAJ13CA | 13.0 | 14.40 | 15.90 | 1 | 5 | 21.50 | 18.60 | 400 | SMA/DO-214AC | |
| SMAJ14A | SMAJ14CA | 14.0 | 15.60 | 17.20 | 1 | 5 | 23.20 | 17.20 | 400 | SMA/DO-214AC | |
| SMAJ15A | SMAJ15CA | 15.0 | 16.70 | 18.50 | 1 | 5 | 24.40 | 16.40 | 400 | SMA/DO-214AC | |
| SMAJ16A | SMAJ16CA | 16.0 | 17.80 | 19.70 | 1 | 5 | 26.00 | 15.30 | 400 | SMA/DO-214AC | |
| SMAJ17A | SMAJ17CA | 17.0 | 18.90 | 20.90 | 1 | 5 | 27.60 | 14.50 | 400 | SMA/DO-214AC | |
| SMAJ18A | SMAJ18CA | 18.0 | 20.00 | 22.10 | 1 | 5 | 29.20 | 13.70 | 400 | SMA/DO-214AC | |
| SMAJ20A | SMAJ20CA | 20.0 | 22.20 | 24.50 | 1 | 5 | 32.40 | 12.30 | 400 | SMA/DO-214AC | |
| SMAJ22A | SMAJ22CA | 22.0 | 24.40 | 26.90 | 1 | 5 | 35.50 | 11.20 | 400 | SMA/DO-214AC | |
| SMAJ24A | SMAJ24CA | 24.0 | 26.70 | 29.50 | 1 | 5 | 38.90 | 10.30 | 400 | SMA/DO-214AC | |
| SMAJ26A | SMAJ26CA | 26.0 | 28.90 | 31.90 | 1 | 5 | 42.10 | 9.50 | 400 | SMA/DO-214AC | |
| SMAJ28A | SMAJ28CA | 28.0 | 31.10 | 34.40 | 1 | 5 | 45.40 | 8.80 | 400 | SMA/DO-214AC | |
| SMAJ30A | SMAJ30CA | 30.0 | 33.30 | 36.80 | 1 | 5 | 48.40 | 8.30 | 400 | SMA/DO-214AC | |
| SMAJ33A | SMAJ33CA | 33.0 | 36.70 | 40.60 | 1 | 5 | 53.30 | 7.50 | 400 | SMA/DO-214AC | |
| SMAJ36A | SMAJ36CA | 36.0 | 40.00 | 44.20 | 1 | 5 | 58.10 | 6.90 | 400 | SMA/DO-214AC | |
| SMAJ40A | SMAJ40CA | 40.0 | 44.40 | 49.10 | 1 | 5 | 64.50 | 6.20 | 400 | SMA/DO-214AC | |
| SMAJ43A | SMAJ43CA | 43.0 | 47.80 | 52.80 | 1 | 5 | 69.40 | 5.70 | 400 | SMA/DO-214AC | |
| SMAJ45A | SMAJ45CA | 45.0 | 50.00 | 55.30 | 1 | 5 | 72.70 | 5.50 | 400 | SMA/DO-214AC | |
| SMAJ48A | SMAJ48CA | 48.0 | 53.30 | 58.90 | 1 | 5 | 77.40 | 5.20 | 400 | SMA/DO-214AC | |
| SMAJ51A | SMAJ51CA | 51.0 | 56.70 | 62.70 | 1 | 5 | 82.40 | 4.90 | 400 | SMA/DO-214AC | |
| SMAJ54A | SMAJ54CA | 54.0 | 60.00 | 66.30 | 1 | 5 | 87.10 | 4.60 | 400 | SMA/DO-214AC | |
| SMAJ58A | SMAJ58CA | 58.0 | 64.40 | 71.20 | 1 | 5 | 93.60 | 4.30 | 400 | SMA/DO-214AC | |
| SMAJ60A | SMAJ60CA | 60.0 | 66.70 | 73.70 | 1 | 5 | 96.80 | 4.10 | 400 | SMA/DO-214AC | |
| SMAJ64A | SMAJ64CA | 64.0 | 71.10 | 78.60 | 1 | 5 | 103.00 | 3.90 | 400 | SMA/DO-214AC | |
| SMAJ70A | SMAJ70CA | 70.0 | 77.80 | 86.00 | 1 | 5 | 113.00 | 3.50 | 400 | SMA/DO-214AC | |
| SMAJ75A | SMAJ75CA | 75.0 | 83.30 | 92.10 | 1 | 5 | 121.00 | 3.30 | 400 | SMA/DO-214AC | |
| SMAJ78A | SMAJ78CA | 78.0 | 86.70 | 95.80 | 1 | 5 | 126.00 | 3.20 | 400 | SMA/DO-214AC | |
| SMAJ85A | SMAJ85CA | 85.0 | 94.40 | 104.00 | 1 | 5 | 137.00 | 2.90 | 400 | SMA/DO-214AC | |
| SMAJ90A | SMAJ90CA | 90.0 | 100.00 | 111.00 | 1 | 5 | 146.00 | 2.70 | 400 | SMA/DO-214AC | |
| SMAJ100A | SMAJ100CA | 100.0 | 111.00 | 123.00 | 1 | 5 | 162.00 | 2.50 | 400 | SMA/DO-214AC | |
| SMAJ110A | SMAJ110CA | 110.0 | 122.00 | 135.00 | 1 | 5 | 177.00 | 2.30 | 400 | SMA/DO-214AC | |
| SMAJ120A | SMAJ120CA | 120.0 | 133.00 | 147.00 | 1 | 5 | 193.00 | 2.00 | 400 | SMA/DO-214AC | |
| SMAJ130A | SMAJ130CA | 130.0 | 144.00 | 159.00 | 1 | 5 | 209.00 | 1.90 | 400 | SMA/DO-214AC | |
| SMAJ150A | SMAJ150CA | 150.0 | 167.00 | 185.00 | 1 | 5 | 243.00 | 1.60 | 400 | SMA/DO-214AC | |
| SMAJ160A | SMAJ160CA | 160.0 | 178.00 | 197.00 | 1 | 5 | 259.00 | 1.50 | 400 | SMA/DO-214AC | |
| SMAJ170A | SMAJ170CA | 170.0 | 189.00 | 209.00 | 1 | 5 | 275.00 | 1.40 | 400 | SMA/DO-214AC | |
| P6KE6.8A | P6KE6.8CA | 5.8 | 6.45 | 7.14 | 10 | 1000 | 10.50 | 57.00 | 600 | DO-15 | |
| P6KE7.5A | P6KE7.5CA | 6.4 | 7.13 | 7.88 | 10 | 500 | 11.30 | 53.00 | 600 | DO-15 | |
| P6KE8.2A | P6KE8.2CA | 7.0 | 7.79 | 8.61 | 10 | 200 | 12.10 | 50.00 | 600 | DO-15 | |
| P6KE9.1A | P6KE9.1CA | 7.8 | 8.65 | 9.50 | 1 | 50 | 13.40 | 45.00 | 600 | DO-15 | |
| P6KE10A | P6KE10CA | 8.6 | 9.50 | 10.50 | 1 | 10 | 14.50 | 41.00 | 600 | DO-15 | |
| P6KE11A | P6KE11CA | 9.4 | 10.50 | 11.60 | 1 | 5 | 15.60 | 38.00 | 600 | DO-15 | |
| P6KE12A | P6KE12CA | 10.2 | 11.40 | 12.60 | 1 | 5 | 16.70 | 36.00 | 600 | DO-15 | |
| P6KE13A | P6KE13CA | 11.1 | 12.40 | 13.70 | 1 | 5 | 18.20 | 33.00 | 600 | DO-15 | |
| P6KE15A | P6KE15CA | 12.8 | 14.30 | 15.80 | 1 | 5 | 21.20 | 28.00 | 600 | DO-15 | |
| P6KE16A | P6KE16CA | 13.6 | 15.20 | 16.80 | 1 | 5 | 22.50 | 27.00 | 600 | DO-15 | |
| P6KE18A | P6KE18CA | 15.3 | 17.10 | 18.90 | 1 | 5 | 25.20 | 24.00 | 600 | DO-15 | |
| P6KE20A | P6KE20CA | 17.1 | 19.00 | 21.00 | 1 | 5 | 27.70 | 22.00 | 600 | DO-15 | |
| P6KE22A | P6KE22CA | 18.8 | 20.90 | 23.10 | 1 | 5 | 30.60 | 20.00 | 600 | DO-15 | |
| P6KE24A | P6KE24CA | 20.5 | 22.80 | 25.20 | 1 | 5 | 33.20 | 18.00 | 600 | DO-15 | |
| P6KE27A | P6KE27CA | 23.1 | 25.70 | 28.40 | 1 | 5 | 37.50 | 16.00 | 600 | DO-15 | |
| P6KE30A | P6KE30CA | 25.6 | 28.50 | 31.50 | 1 | 5 | 41.40 | 14.40 | 600 | DO-15 | |
| P6KE33A | P6KE33CA | 28.2 | 31.40 | 34.70 | 1 | 5 | 45.70 | 13.20 | 600 | DO-15 | |
| P6KE36A | P6KE36CA | 30.8 | 34.20 | 37.80 | 1 | 5 | 49.90 | 12.00 | 600 | DO-15 | |
| P6KE39A | P6KE39CA | 33.3 | 37.10 | 41.00 | 1 | 5 | 53.90 | 11.20 | 600 | DO-15 | |
| P6KE43A | P6KE43CA | 36.8 | 40.90 | 45.20 | 1 | 5 | 59.30 | 10.10 | 600 | DO-15 | |
| P6KE47A | P6KE47CA | 40.2 | 44.70 | 49.40 | 1 | 5 | 64.80 | 9.30 | 600 | DO-15 | |
| P6KE51A | P6KE51CA | 43.6 | 48.50 | 53.60 | 1 | 5 | 70.10 | 8.60 | 600 | DO-15 | |
| P6KE56A | P6KE56CA | 47.8 | 53.20 | 58.80 | 1 | 5 | 77.00 | 7.80 | 600 | DO-15 | |
| P6KE62A | P6KE62CA | 53.0 | 58.90 | 65.10 | 1 | 5 | 85.00 | 7.10 | 600 | DO-15 | |
| P6KE68A | P6KE68CA | 58.1 | 64.60 | 71.40 | 1 | 5 | 92.00 | 6.50 | 600 | DO-15 | |
| P6KE75A | P6KE75CA | 64.1 | 71.30 | 78.80 | 1 | 5 | 103.00 | 5.80 | 600 | DO-15 | |
| P6KE82A | P6KE82CA | 70.1 | 77.90 | 86.10 | 1 | 5 | 113.00 | 5.40 | 600 | DO-15 | |
| P6KE91A | P6KE91CA | 77.8 | 86.50 | 95.50 | 1 | 5 | 125.00 | 4.90 | 600 | DO-15 | |
| P6KE100A | P6KE100CA | 85.5 | 95.00 | 105.00 | 1 | 5 | 137.00 | 4.50 | 600 | DO-15 | |
| P6KE110A | P6KE110CA | 94.0 | 105.00 | 116.00 | 1 | 5 | 152.00 | 4.00 | 600 | DO-15 | |
| P6KE120A | P6KE120CA | 102.0 | 114.00 | 126.00 | 1 | 5 | 165.00 | 3.70 | 600 | DO-15 | |
| P6KE130A | P6KE130CA | 111.0 | 124.00 | 137.00 | 1 | 5 | 179.00 | 3.40 | 600 | DO-15 | |
| P6KE150A | P6KE150CA | 128.0 | 143.00 | 158.00 | 1 | 5 | 207.00 | 2.90 | 600 | DO-15 | |
| P6KE160A | P6KE160CA | 136.0 | 152.00 | 168.00 | 1 | 5 | 219.00 | 2.80 | 600 | DO-15 | |
| P6KE170A | P6KE170CA | 145.0 | 162.00 | 179.00 | 1 | 5 | 234.00 | 2.60 | 600 | DO-15 | |
| P6KE180A | P6KE180CA | 154.0 | 171.00 | 189.00 | 1 | 5 | 246.00 | 2.50 | 600 | DO-15 | |
| P6KE200A | P6KE200CA | 171.0 | 190.00 | 210.00 | 1 | 5 | 274.00 | 2.20 | 600 | DO-15 | |
| P6KE220A | P6KE220CA | 185.0 | 209.00 | 231.00 | 1 | 5 | 328.00 | 1.90 | 600 | DO-15 | |
| P6KE250A | P6KE250CA | 214.0 | 237.00 | 263.00 | 1 | 5 | 344.00 | 1.80 | 600 | DO-15 | |
| P6KE300A | P6KE300CA | 256.0 | 285.00 | 315.00 | 1 | 5 | 414.00 | 1.50 | 600 | DO-15 | |
| P6KE350A | P6KE350CA | 300.0 | 332.00 | 368.00 | 1 | 5 | 482.00 | 1.30 | 600 | DO-15 | |
| P6KE400A | P6KE400CA | 342.0 | 380.00 | 420.00 | 1 | 5 | 548.00 | 1.10 | 600 | DO-15 | |
| P6KE440A | P6KE440CA | 376.0 | 418.00 | 462.00 | 1 | 5 | 600.00 | 1.00 | 600 | DO-15 | |
| SMBJ5.0A | SMBJ5.0CA | 5.0 | 6.40 | 7.25 | 10 | 800 | 9.20 | 65.20 | 600 | SMB/DO-214AA | |
| SMBJ6.0A | SMBJ6.0CA | 6.0 | 6.67 | 7.67 | 10 | 800 | 10.30 | 58.30 | 600 | SMB/DO-214AA | |
| SMBJ6.5A | SMBJ6.5CA | 6.5 | 7.22 | 8.30 | 10 | 500 | 11.20 | 53.60 | 600 | SMB/DO-214AA | |
| SMBJ7.0A | SMBJ7.0CA | 7.0 | 7.78 | 8.95 | 10 | 200 | 12.00 | 50.00 | 600 | SMB/DO-214AA | |
| SMBJ7.5A | SMBJ7.5CA | 7.5 | 8.33 | 9.58 | 1 | 100 | 12.90 | 46.50 | 600 | SMB/DO-214AA | |
| SMBJ8.0A | SMBJ8.0CA | 8.0 | 8.89 | 10.23 | 1 | 50 | 13.60 | 44.10 | 600 | SMB/DO-214AA | |
| SMBJ8.5A | SMBJ8.5CA | 8.5 | 9.44 | 10.82 | 1 | 10 | 14.40 | 41.70 | 600 | SMB/DO-214AA | |
| SMBJ9.0A | SMBJ9.0CA | 9.0 | 10.00 | 11.50 | 1 | 5 | 15.40 | 39.00 | 600 | SMB/DO-214AA | |
| SMBJ10A | SMBJ10CA | 10.0 | 11.10 | 12.80 | 1 | 5 | 17.00 | 35.30 | 600 | SMB/DO-214AA | |
| SMBJ11A | SMBJ11CA | 11.0 | 12.20 | 14.00 | 1 | 5 | 18.20 | 33.00 | 600 | SMB/DO-214AA | |
| SMBJ12A | SMBJ12CA | 12.0 | 13.30 | 15.30 | 1 | 5 | 19.90 | 30.20 | 600 | SMB/DO-214AA | |
| SMBJ13A | SMBJ13CA | 13.0 | 14.40 | 16.50 | 1 | 5 | 21.50 | 27.90 | 600 | SMB/DO-214AA | |
| SMBJ14A | SMBJ14CA | 14.0 | 15.60 | 17.90 | 1 | 5 | 23.20 | 25.80 | 600 | SMB/DO-214AA | |
| SMBJ15A | SMBJ15CA | 15.0 | 16.70 | 19.20 | 1 | 5 | 24.40 | 24.00 | 600 | SMB/DO-214AA | |
| SMBJ16A | SMBJ16CA | 16.0 | 17.80 | 20.50 | 1 | 5 | 26.00 | 23.10 | 600 | SMB/DO-214AA | |
| SMBJ17A | SMBJ17CA | 17.0 | 18.90 | 21.70 | 1 | 5 | 27.60 | 21.70 | 600 | SMB/DO-214AA | |
| SMBJ18A | SMBJ18CA | 18.0 | 20.00 | 23.30 | 1 | 5 | 29.20 | 20.50 | 600 | SMB/DO-214AA | |
| SMBJ20A | SMBJ20CA | 20.0 | 22.20 | 25.50 | 1 | 5 | 32.40 | 18.50 | 600 | SMB/DO-214AA | |
| SMBJ22A | SMBJ22CA | 22.0 | 24.40 | 28.00 | 1 | 5 | 35.50 | 16.90 | 600 | SMB/DO-214AA | |
| SMBJ24A | SMBJ24CA | 24.0 | 26.70 | 30.70 | 1 | 5 | 38.90 | 15.40 | 600 | SMB/DO-214AA | |
| SMBJ26A | SMBJ26CA | 26.0 | 28.90 | 33.20 | 1 | 5 | 42.10 | 14.20 | 600 | SMB/DO-214AA | |
| SMBJ28A | SMBJ28CA | 28.0 | 31.10 | 35.80 | 1 | 5 | 45.40 | 13.20 | 600 | SMB/DO-214AA | |
| SMBJ30A | SMBJ30CA | 30.0 | 33.30 | 38.30 | 1 | 5 | 48.40 | 12.40 | 600 | SMB/DO-214AA | |
| SMBJ33A | SMBJ33CA | 33.0 | 36.70 | 42.20 | 1 | 5 | 53.30 | 11.30 | 600 | SMB/DO-214AA | |
| SMBJ36A | SMBJ36CA | 36.0 | 40.00 | 46.00 | 1 | 5 | 58.10 | 10.30 | 600 | SMB/DO-214AA | |
| SMBJ40A | SMBJ40CA | 40.0 | 44.40 | 51.10 | 1 | 5 | 64.50 | 9.30 | 600 | SMB/DO-214AA | |
| SMBJ43A | SMBJ43CA | 43.0 | 47.80 | 54.90 | 1 | 5 | 69.40 | 8.60 | 600 | SMB/DO-214AA | |
| SMBJ45A | SMBJ45CA | 45.0 | 50.00 | 57.50 | 1 | 5 | 72.70 | 8.30 | 600 | SMB/DO-214AA | |
| SMBJ48A | SMBJ48CA | 48.0 | 53.30 | 61.30 | 1 | 5 | 77.40 | 7.70 | 600 | SMB/DO-214AA | |
| SMBJ51A | SMBJ51CA | 51.0 | 56.70 | 65.20 | 1 | 5 | 82.40 | 7.30 | 600 | SMB/DO-214AA | |
| SMBJ54A | SMBJ54CA | 54.0 | 60.00 | 69.00 | 1 | 5 | 87.10 | 6.90 | 600 | SMB/DO-214AA | |
| SMBJ58A | SMBJ58CA | 58.0 | 64.40 | 74.10 | 1 | 5 | 93.60 | 6.40 | 600 | SMB/DO-214AA | |
| SMBJ60A | SMBJ60CA | 60.0 | 66.70 | 76.70 | 1 | 5 | 96.80 | 6.20 | 600 | SMB/DO-214AA | |
| SMBJ64A | SMBJ64CA | 64.0 | 71.10 | 81.80 | 1 | 5 | 103.00 | 5.80 | 600 | SMB/DO-214AA | |
| SMBJ70A | SMBJ70CA | 70.0 | 77.80 | 89.50 | 1 | 5 | 113.00 | 5.30 | 600 | SMB/DO-214AA | |
| SMBJ75A | SMBJ75CA | 75.0 | 83.30 | 95.80 | 1 | 5 | 121.00 | 4.90 | 600 | SMB/DO-214AA | |
| SMBJ78A | SMBJ78CA | 78.0 | 86.70 | 99.70 | 1 | 5 | 126.00 | 4.70 | 600 | SMB/DO-214AA | |
| SMBJ85A | SMBJ85CA | 85.0 | 94.40 | 108.20 | 1 | 5 | 137.00 | 4.40 | 600 | SMB/DO-214AA | |
| SMBJ90A | SMBJ90CA | 90.0 | 100.00 | 115.50 | 1 | 5 | 146.00 | 4.10 | 600 | SMB/DO-214AA | |
| SMBJ100A | SMBJ100CA | 100.0 | 111.00 | 128.00 | 1 | 5 | 162.00 | 3.70 | 600 | SMB/DO-214AA | |
| SMBJ110A | SMBJ110CA | 110.0 | 122.00 | 140.50 | 1 | 5 | 177.00 | 3.50 | 600 | SMB/DO-214AA | |
| SMBJ120A | SMBJ120CA | 120.0 | 133.00 | 153.00 | 1 | 5 | 193.00 | 3.10 | 600 | SMB/DO-214AA | |
| SMBJ130A | SMBJ130CA | 130.0 | 144.00 | 165.50 | 1 | 5 | 209.00 | 2.90 | 600 | SMB/DO-214AA | |
| SMBJ150A | SMBJ150CA | 150.0 | 167.00 | 192.50 | 1 | 5 | 243.00 | 2.50 | 600 | SMB/DO-214AA | |
| SMBJ160A | SMBJ160CA | 160.0 | 178.00 | 205.00 | 1 | 5 | 259.00 | 2.30 | 600 | SMB/DO-214AA | |
| SMBJ170A | SMBJ170CA | 170.0 | 189.00 | 217.50 | 1 | 5 | 275.00 | 2.20 | 600 | SMB/DO-214AA | |
| 1.5KE6.8A | 1.5KE6.8CA | 5.8 | 6.45 | 7.14 | 10 | 1000 | 10.50 | 144.80 | 1500 | DO-201 | |
| 1.5KE7.5A | 1.5KE7.5CA | 6.4 | 7.13 | 7.88 | 10 | 500 | 11.30 | 134.50 | 1500 | DO-201 | |
| 1.5KE8.2A | 1.5KE8.2CA | 7.0 | 7.79 | 8.61 | 10 | 200 | 12.10 | 125.60 | 1500 | DO-201 | |
| 1.5KE9.1A | 1.5KE9.1CA | 7.8 | 8.65 | 9.50 | 1 | 50 | 13.40 | 113.40 | 1500 | DO-201 | |
| 1.5KE10A | 1.5KE10CA | 8.6 | 9.50 | 10.50 | 1 | 10 | 14.50 | 104.80 | 1500 | DO-201 | |
| 1.5KE11A | 1.5KE11CA | 9.4 | 10.50 | 11.60 | 1 | 5 | 15.60 | 97.40 | 1500 | DO-201 | |
| 1.5KE12A | 1.5KE12CA | 10.2 | 11.40 | 12.60 | 1 | 5 | 16.70 | 91.00 | 1500 | DO-201 | |
| 1.5KE13A | 1.5KE13CA | 11.1 | 12.40 | 13.70 | 1 | 5 | 18.20 | 83.50 | 1500 | DO-201 | |
| 1.5KE15A | 1.5KE15CA | 12.8 | 14.30 | 15.80 | 1 | 5 | 21.20 | 71.70 | 1500 | DO-201 | |
| 1.5KE16A | 1.5KE16CA | 13.6 | 15.20 | 16.80 | 1 | 5 | 22.50 | 67.60 | 1500 | DO-201 | |
| 1.5KE18A | 1.5KE18CA | 15.3 | 17.10 | 18.90 | 1 | 5 | 25.20 | 60.30 | 1500 | DO-201 | |
| 1.5KE20A | 1.5KE20CA | 17.1 | 19.00 | 21.00 | 1 | 5 | 27.70 | 54.90 | 1500 | DO-201 | |
| 1.5KE22A | 1.5KE22CA | 18.8 | 20.90 | 23.10 | 1 | 5 | 30.60 | 49.70 | 1500 | DO-201 | |
| 1.5KE24A | 1.5KE24CA | 20.5 | 22.80 | 25.20 | 1 | 5 | 33.20 | 45.80 | 1500 | DO-201 | |
| 1.5KE27A | 1.5KE27CA | 23.1 | 25.70 | 28.40 | 1 | 5 | 37.50 | 40.50 | 1500 | DO-201 | |
| 1.5KE30A | 1.5KE30CA | 25.6 | 28.50 | 31.50 | 1 | 5 | 41.40 | 36.70 | 1500 | DO-201 | |
| 1.5KE33A | 1.5KE33CA | 28.2 | 31.40 | 34.70 | 1 | 5 | 45.70 | 33.30 | 1500 | DO-201 | |
| 1.5KE36A | 1.5KE36CA | 30.8 | 34.20 | 37.80 | 1 | 5 | 49.90 | 30.50 | 1500 | DO-201 | |
| 1.5KE39A | 1.5KE39CA | 33.3 | 37.10 | 41.00 | 1 | 5 | 53.90 | 28.20 | 1500 | DO-201 | |
| 1.5KE43A | 1.5KE43CA | 36.8 | 40.90 | 45.20 | 1 | 5 | 59.30 | 25.60 | 1500 | DO-201 | |
| 1.5KE47A | 1.5KE47CA | 40.2 | 44.70 | 49.40 | 1 | 5 | 64.80 | 23.50 | 1500 | DO-201 | |
| 1.5KE51A | 1.5KE51CA | 43.6 | 48.50 | 53.60 | 1 | 5 | 70.10 | 21.70 | 1500 | DO-201 | |
| 1.5KE56A | 1.5KE56CA | 47.8 | 53.20 | 58.80 | 1 | 5 | 77.00 | 19.70 | 1500 | DO-201 | |
| 1.5KE62A | 1.5KE62CA | 53.0 | 58.90 | 65.10 | 1 | 5 | 85.00 | 17.90 | 1500 | DO-201 | |
| 1.5KE68A | 1.5KE68CA | 58.1 | 64.60 | 71.40 | 1 | 5 | 92.00 | 16.50 | 1500 | DO-201 | |
| 1.5KE75A | 1.5KE75CA | 64.1 | 71.30 | 78.80 | 1 | 5 | 103.00 | 14.80 | 1500 | DO-201 | |
| 1.5KE82A | 1.5KE82CA | 70.1 | 77.90 | 86.10 | 1 | 5 | 113.00 | 13.50 | 1500 | DO-201 | |
| 1.5KE91A | 1.5KE91CA | 77.8 | 86.50 | 95.50 | 1 | 5 | 125.00 | 12.20 | 1500 | DO-201 | |
| 1.5KE100A | 1.5KE100CA | 85.5 | 95.00 | 105.00 | 1 | 5 | 137.00 | 11.10 | 1500 | DO-201 | |
| 1.5KE110A | 1.5KE110CA | 94.0 | 105.00 | 116.00 | 1 | 5 | 152.00 | 10.00 | 1500 | DO-201 | |
| 1.5KE120A | 1.5KE120CA | 102.0 | 114.00 | 126.00 | 1 | 5 | 165.00 | 9.20 | 1500 | DO-201 | |
| 1.5KE130A | 1.5KE130CA | 111.0 | 124.00 | 137.00 | 1 | 5 | 179.00 | 8.50 | 1500 | DO-201 | |
| 1.5KE150A | 1.5KE150CA | 128.0 | 143.00 | 158.00 | 1 | 5 | 207.00 | 7.30 | 1500 | DO-201 | |
| 1.5KE160A | 1.5KE160CA | 136.0 | 152.00 | 168.00 | 1 | 5 | 219.00 | 6.90 | 1500 | DO-201 | |
| 1.5KE170A | 1.5KE170CA | 145.0 | 162.00 | 179.00 | 1 | 5 | 234.00 | 6.50 | 1500 | DO-201 | |
| 1.5KE180A | 1.5KE180CA | 154.0 | 171.00 | 189.00 | 1 | 5 | 246.00 | 6.20 | 1500 | DO-201 | |
| 1.5KE200A | 1.5KE200CA | 171.0 | 190.00 | 210.00 | 1 | 5 | 274.00 | 5.50 | 1500 | DO-201 | |
| 1.5KE220A | 1.5KE220CA | 185.0 | 209.00 | 231.00 | 1 | 5 | 328.00 | 4.60 | 1500 | DO-201 | |
| 1.5KE250A | 1.5KE250CA | 214.0 | 237.00 | 263.00 | 1 | 5 | 344.00 | 4.40 | 1500 | DO-201 | |
| 1.5KE300A | 1.5KE300CA | 256.0 | 285.00 | 315.00 | 1 | 5 | 414.00 | 3.70 | 1500 | DO-201 | |
| 1.5KE350A | 1.5KE350CA | 300.0 | 332.00 | 368.00 | 1 | 5 | 482.00 | 3.20 | 1500 | DO-201 | |
| 1.5KE400A | 1.5KE400CA | 342.0 | 380.00 | 420.00 | 1 | 5 | 548.00 | 2.80 | 1500 | DO-201 | |
| 1.5KE440A | 1.5KE440CA | 376.0 | 418.00 | 462.00 | 1 | 5 | 600.00 | 2.50 | 1500 | DO-201 | |
| SMCJ5.0A | SMCJ5.0CA | 5.0 | 6.40 | 7.25 | 10 | 1000 | 9.20 | 163.00 | 1500 | SMC/DO-214AB | |
| SMCJ6.0A | SMCJ6.0CA | 6.0 | 6.67 | 7.67 | 10 | 1000 | 10.30 | 145.60 | 1500 | SMC/DO-214AB | |
| SMCJ6.5A | SMCJ6.5CA | 6.5 | 7.22 | 8.30 | 10 | 500 | 11.20 | 133.90 | 1500 | SMC/DO-214AB | |
| SMCJ7.0A | SMCJ7.0CA | 7.0 | 7.78 | 8.95 | 10 | 200 | 12.00 | 125.00 | 1500 | SMC/DO-214AB | |
| SMCJ7.5A | SMCJ7.5CA | 7.5 | 8.33 | 9.58 | 1 | 100 | 12.90 | 116.30 | 1500 | SMC/DO-214AB | |
| SMCJ8.0A | SMCJ8.0CA | 8.0 | 8.89 | 10.23 | 1 | 50 | 13.60 | 110.30 | 1500 | SMC/DO-214AB | |
| SMCJ8.5A | SMCJ8.5CA | 8.5 | 9.44 | 10.82 | 1 | 10 | 14.40 | 104.20 | 1500 | SMC/DO-214AB | |
| SMCJ9.0A | SMCJ9.0CA | 9.0 | 10.00 | 11.50 | 1 | 5 | 15.40 | 97.40 | 1500 | SMC/DO-214AB | |
| SMCJ10A | SMCJ10CA | 10.0 | 11.10 | 12.80 | 1 | 5 | 17.00 | 88.20 | 1500 | SMC/DO-214AB | |
| SMCJ11A | SMCJ11CA | 11.0 | 12.20 | 14.00 | 1 | 5 | 18.20 | 82.40 | 1500 | SMC/DO-214AB | |
| SMCJ12A | SMCJ12CA | 12.0 | 13.30 | 15.30 | 1 | 5 | 19.90 | 75.30 | 1500 | SMC/DO-214AB | |
| SMCJ13A | SMCJ13CA | 13.0 | 14.40 | 16.50 | 1 | 5 | 21.50 | 69.70 | 1500 | SMC/DO-214AB | |
| SMCJ14A | SMCJ14CA | 14.0 | 15.60 | 17.90 | 1 | 5 | 23.20 | 64.70 | 1500 | SMC/DO-214AB | |
| SMCJ15A | SMCJ15CA | 15.0 | 16.70 | 19.20 | 1 | 5 | 24.40 | 61.50 | 1500 | SMC/DO-214AB | |
| SMCJ16A | SMCJ16CA | 16.0 | 17.80 | 20.50 | 1 | 5 | 26.00 | 57.70 | 1500 | SMC/DO-214AB | |
| SMCJ17A | SMCJ17CA | 17.0 | 18.90 | 21.70 | 1 | 5 | 27.60 | 53.30 | 1500 | SMC/DO-214AB | |
| SMCJ18A | SMCJ18CA | 18.0 | 20.00 | 23.30 | 1 | 5 | 29.20 | 51.40 | 1500 | SMC/DO-214AB | |
| SMCJ20A | SMCJ20CA | 20.0 | 22.20 | 25.50 | 1 | 5 | 32.40 | 46.30 | 1500 | SMC/DO-214AB | |
| SMCJ22A | SMCJ22CA | 22.0 | 24.40 | 28.00 | 1 | 5 | 35.50 | 42.20 | 1500 | SMC/DO-214AB | |
| SMCJ24A | SMCJ24CA | 24.0 | 26.70 | 30.70 | 1 | 5 | 38.90 | 38.60 | 1500 | SMC/DO-214AB | |
| SMCJ26A | SMCJ26CA | 26.0 | 28.90 | 33.20 | 1 | 5 | 42.10 | 35.60 | 1500 | SMC/DO-214AB | |
| SMCJ28A | SMCJ28CA | 28.0 | 31.10 | 35.80 | 1 | 5 | 45.40 | 33.00 | 1500 | SMC/DO-214AB | |
| SMCJ30A | SMCJ30CA | 30.0 | 33.30 | 38.30 | 1 | 5 | 48.40 | 31.00 | 1500 | SMC/DO-214AB | |
| SMCJ33A | SMCJ33CA | 33.0 | 36.70 | 42.20 | 1 | 5 | 53.30 | 28.10 | 1500 | SMC/DO-214AB | |
| SMCJ36A | SMCJ36CA | 36.0 | 40.00 | 46.00 | 1 | 5 | 58.10 | 25.80 | 1500 | SMC/DO-214AB | |
| SMCJ40A | SMCJ40CA | 40.0 | 44.40 | 51.10 | 1 | 5 | 64.50 | 23.20 | 1500 | SMC/DO-214AB | |
| SMCJ43A | SMCJ43CA | 43.0 | 47.80 | 54.90 | 1 | 5 | 69.40 | 21.60 | 1500 | SMC/DO-214AB | |
| SMCJ45A | SMCJ45CA | 45.0 | 50.00 | 57.50 | 1 | 5 | 72.70 | 20.60 | 1500 | SMC/DO-214AB | |
| SMCJ48A | SMCJ48CA | 48.0 | 53.30 | 61.30 | 1 | 5 | 77.40 | 19.40 | 1500 | SMC/DO-214AB | |
| SMCJ51A | SMCJ51CA | 51.0 | 56.70 | 65.20 | 1 | 5 | 82.40 | 18.20 | 1500 | SMC/DO-214AB | |
| SMCJ54A | SMCJ54CA | 54.0 | 60.00 | 69.00 | 1 | 5 | 87.10 | 17.20 | 1500 | SMC/DO-214AB | |
| SMCJ58A | SMCJ58CA | 58.0 | 64.40 | 74.10 | 1 | 5 | 93.60 | 16.00 | 1500 | SMC/DO-214AB | |
| SMCJ60A | SMCJ60CA | 60.0 | 66.70 | 76.70 | 1 | 5 | 96.80 | 15.50 | 1500 | SMC/DO-214AB | |
| SMCJ64A | SMCJ64CA | 64.0 | 71.10 | 81.80 | 1 | 5 | 103.00 | 14.60 | 1500 | SMC/DO-214AB | |
| SMCJ70A | SMCJ70CA | 70.0 | 77.80 | 89.50 | 1 | 5 | 113.00 | 13.30 | 1500 | SMC/DO-214AB | |
| SMCJ75A | SMCJ75CA | 75.0 | 83.30 | 95.80 | 1 | 5 | 121.00 | 12.40 | 1500 | SMC/DO-214AB | |
| SMCJ78A | SMCJ78CA | 78.0 | 86.70 | 99.70 | 1 | 5 | 126.00 | 11.40 | 1500 | SMC/DO-214AB | |
| SMCJ85A | SMCJ85CA | 85.0 | 94.40 | 108.20 | 1 | 5 | 137.00 | 10.40 | 1500 | SMC/DO-214AB | |
| SMCJ90A | SMCJ90CA | 90.0 | 100.00 | 115.50 | 1 | 5 | 146.00 | 10.30 | 1500 | SMC/DO-214AB | |
| SMCJ100A | SMCJ100CA | 100.0 | 111.00 | 128.00 | 1 | 5 | 162.00 | 9.30 | 1500 | SMC/DO-214AB | |
| SMCJ110A | SMCJ110CA | 110.0 | 122.00 | 140.50 | 1 | 5 | 177.00 | 8.40 | 1500 | SMC/DO-214AB | |
| SMCJ120A | SMCJ120CA | 120.0 | 133.00 | 153.00 | 1 | 5 | 193.00 | 7.90 | 1500 | SMC/DO-214AB | |
| SMCJ130A | SMCJ130CA | 130.0 | 144.00 | 165.50 | 1 | 5 | 209.00 | 7.20 | 1500 | SMC/DO-214AB | |
| SMCJ150A | SMCJ150CA | 150.0 | 167.00 | 192.50 | 1 | 5 | 243.00 | 6.20 | 1500 | SMC/DO-214AB | |
| SMCJ160A | SMCJ160CA | 160.0 | 178.00 | 205.00 | 1 | 5 | 259.00 | 5.80 | 1500 | SMC/DO-214AB | |
| SMCJ170A | SMCJ170CA | 170.0 | 189.00 | 217.50 | 1 | 5 | 275.00 | 5.50 | 1500 | SMC/DO-214AB | |
| SMDJ5.0A | SMDJ5.0CA | 5.0 | 6.40 | 7.00 | 10 | 800 | 9.20 | 326.09 | 3000 | SMC/DO-214AB | |
| SMDJ6.0A | SMDJ6.0CA | 6.0 | 6.67 | 7.37 | 10 | 800 | 10.30 | 291.26 | 3000 | SMC/DO-214AB | |
| SMDJ6.5A | SMDJ6.5CA | 6.5 | 7.22 | 7.98 | 10 | 500 | 11.20 | 267.86 | 3000 | SMC/DO-214AB | |
| SMDJ7.0A | SMDJ7.0CA | 7.0 | 7.78 | 8.60 | 10 | 200 | 12.00 | 250.00 | 3000 | SMC/DO-214AB | |
| SMDJ7.5A | SMDJ7.5CA | 7.5 | 8.33 | 9.21 | 1 | 100 | 12.90 | 232.56 | 3000 | SMC/DO-214AB | |
| SMDJ8.0A | SMDJ8.0CA | 8.0 | 8.89 | 9.83 | 1 | 50 | 12.90 | 220.59 | 3000 | SMC/DO-214AB | |
| SMDJ8.5A | SMDJ8.5CA | 8.5 | 9.44 | 10.40 | 1 | 20 | 14.40 | 208.33 | 3000 | SMC/DO-214AB | |
| SMDJ9.0A | SMDJ9.0CA | 9.0 | 10.00 | 11.10 | 1 | 10 | 15.40 | 194.81 | 3000 | SMC/DO-214AB | |
| SMDJ10A | SMDJ10CA | 10.0 | 11.10 | 12.30 | 1 | 2 | 17.00 | 176.47 | 3000 | SMC/DO-214AB | |
| SMDJ11A | SMDJ11CA | 11.0 | 12.20 | 13.50 | 1 | 2 | 18.20 | 164.84 | 3000 | SMC/DO-214AB | |
| SMDJ12A | SMDJ12CA | 12.0 | 13.30 | 14.70 | 1 | 2 | 19.90 | 150.75 | 3000 | SMC/DO-214AB | |
| SMDJ13A | SMDJ13CA | 13.0 | 14.40 | 15.90 | 1 | 2 | 21.50 | 139.53 | 3000 | SMC/DO-214AB | |
| SMDJ14A | SMDJ14CA | 14.0 | 15.60 | 17.20 | 1 | 2 | 23.20 | 129.31 | 3000 | SMC/DO-214AB | |
| SMDJ15A | SMDJ15CA | 15.0 | 16.70 | 18.50 | 1 | 2 | 24.40 | 122.95 | 3000 | SMC/DO-214AB | |
| SMDJ16A | SMDJ16CA | 16.0 | 17.80 | 19.70 | 1 | 2 | 26.00 | 115.38 | 3000 | SMC/DO-214AB | |
| SMDJ17A | SMDJ17CA | 17.0 | 18.90 | 20.90 | 1 | 2 | 27.60 | 108.70 | 3000 | SMC/DO-214AB | |
| SMDJ18A | SMDJ18CA | 18.0 | 20.00 | 22.10 | 1 | 2 | 29.20 | 102.74 | 3000 | SMC/DO-214AB | |
| SMDJ19A | SMDJ19CA | 19.0 | 21.00 | 23.30 | 1 | 2 | 30.80 | 97.47 | 3000 | SMC/DO-214AB | |
| SMDJ20A | SMDJ20CA | 20.0 | 22.20 | 24.50 | 1 | 2 | 32.40 | 92.59 | 3000 | SMC/DO-214AB | |
| SMDJ22A | SMDJ22CA | 22.0 | 24.40 | 26.90 | 1 | 2 | 35.50 | 84.51 | 3000 | SMC/DO-214AB | |
| SMDJ24A | SMDJ24CA | 24.0 | 26.70 | 29.50 | 1 | 2 | 38.90 | 77.14 | 3000 | SMC/DO-214AB | |
| SMDJ26A | SMDJ26CA | 26.0 | 28.90 | 31.90 | 1 | 2 | 42.10 | 71.26 | 3000 | SMC/DO-214AB | |
| SMDJ28A | SMDJ28CA | 28.0 | 31.10 | 34.40 | 1 | 2 | 45.40 | 66.08 | 3000 | SMC/DO-214AB | |
| SMDJ30A | SMDJ30CA | 30.0 | 33.30 | 36.80 | 1 | 2 | 48.40 | 61.98 | 3000 | SMC/DO-214AB | |
| SMDJ33A | SMDJ33CA | 33.0 | 36.70 | 40.60 | 1 | 2 | 53.30 | 56.29 | 3000 | SMC/DO-214AB | |
| SMDJ36A | SMDJ36CA | 36.0 | 40.00 | 44.20 | 1 | 2 | 58.10 | 51.64 | 3000 | SMC/DO-214AB | |
| SMDJ40A | SMDJ40CA | 40.0 | 44.40 | 49.10 | 1 | 2 | 64.50 | 46.51 | 3000 | SMC/DO-214AB | |
| SMDJ43A | SMDJ43CA | 43.0 | 47.80 | 52.80 | 1 | 2 | 69.40 | 43.23 | 3000 | SMC/DO-214AB | |
| SMDJ45A | SMDJ45CA | 45.0 | 50.00 | 55.30 | 1 | 2 | 72.70 | 41.27 | 3000 | SMC/DO-214AB | |
| SMDJ48A | SMDJ48CA | 48.0 | 53.30 | 58.90 | 1 | 2 | 77.40 | 38.76 | 3000 | SMC/DO-214AB | |
| SMDJ51A | SMDJ51CA | 51.0 | 56.70 | 62.70 | 1 | 2 | 82.40 | 36.41 | 3000 | SMC/DO-214AB | |
| SMDJ54A | SMDJ54CA | 54.0 | 60.00 | 66.30 | 1 | 2 | 87.10 | 34.44 | 3000 | SMC/DO-214AB | |
| SMDJ58A | SMDJ58CA | 58.0 | 64.40 | 71.20 | 1 | 2 | 93.60 | 32.05 | 3000 | SMC/DO-214AB | |
| SMDJ60A | SMDJ60CA | 60.0 | 66.70 | 73.70 | 1 | 2 | 96.80 | 30.99 | 3000 | SMC/DO-214AB | |
| SMDJ64A | SMDJ64CA | 64.0 | 71.10 | 78.60 | 1 | 2 | 103.00 | 29.13 | 3000 | SMC/DO-214AB | |
| SMDJ70A | SMDJ70CA | 70.0 | 77.80 | 86.00 | 1 | 2 | 113.00 | 26.55 | 3000 | SMC/DO-214AB | |
| SMDJ75A | SMDJ75CA | 75.0 | 83.30 | 92.10 | 1 | 2 | 121.00 | 24.79 | 3000 | SMC/DO-214AB | |
| SMDJ78A | SMDJ78CA | 78.0 | 86.70 | 95.80 | 1 | 2 | 126.00 | 23.81 | 3000 | SMC/DO-214AB | |
| SMDJ85A | SMDJ85CA | 85.0 | 94.40 | 104.00 | 1 | 2 | 137.00 | 21.90 | 3000 | SMC/DO-214AB | |
| SMDJ90A | SMDJ90CA | 90.0 | 100.00 | 111.00 | 1 | 2 | 146.00 | 20.55 | 3000 | SMC/DO-214AB | |
| SMDJ100A | SMDJ100CA | 100.0 | 111.00 | 123.00 | 1 | 2 | 162.00 | 18.52 | 3000 | SMC/DO-214AB | |
| SMDJ110A | SMDJ110CA | 110.0 | 122.00 | 135.00 | 1 | 2 | 177.00 | 16.95 | 3000 | SMC/DO-214AB | |
| SMDJ120A | SMDJ120CA | 120.0 | 133.00 | 147.00 | 1 | 2 | 193.00 | 15.54 | 3000 | SMC/DO-214AB | |
| SMDJ130A | SMDJ130CA | 130.0 | 144.00 | 159.00 | 1 | 2 | 226.80 | 13.23 | 3000 | SMC/DO-214AB | |
| SMDJ140A | SMDJ140CA | 140.0 | 155.00 | 171.00 | 1 | 2 | 209.00 | 14.35 | 3000 | SMC/DO-214AB | |
| SMDJ150A | SMDJ150CA | 150.0 | 167.00 | 185.00 | 1 | 2 | 243.00 | 12.35 | 3000 | SMC/DO-214AB | |
| SMDJ160A | SMDJ160CA | 160.0 | 178.00 | 197.00 | 1 | 2 | 259.00 | 11.58 | 3000 | SMC/DO-214AB | |
| SMDJ170A | SMDJ170CA | 170.0 | 189.00 | 209.00 | 1 | 2 | 275.00 | 10.91 | 3000 | SMC/DO-214AB | |
| SMDJ180A | SMDJ180CA | 180.0 | 201.00 | 220.00 | 1 | 2 | 291.60 | 10.29 | 3000 | SMC/DO-214AB | |
| SMDJ220A | SMDJ220CA | 220.0 | 246.00 | 272.00 | 1 | 2 | 356.00 | 8.43 | 3000 | SMC/DO-214AB | |
| 5KP5.0A | 5KP5.0CA | 5.0 | 6.40 | 7.00 | 50 | 2000 | 9.20 | 543.00 | 5000 | R-6 | |
| 5KP6.0A | 5KP6.0CA | 6.0 | 6.67 | 7.37 | 50 | 5000 | 10.30 | 485.00 | 5000 | R-6 | |
| 5KP6.5A | 5KP6.5CA | 6.5 | 7.22 | 7.98 | 50 | 2000 | 11.20 | 446.00 | 5000 | R-6 | |
| 5KP7.0A | 5KP7.0CA | 7.0 | 7.78 | 8.60 | 50 | 1000 | 12.00 | 417.00 | 5000 | R-6 | |
| 5KP7.5A | 5KP7.5CA | 7.5 | 8.33 | 9.21 | 5 | 250 | 12.90 | 388.00 | 5000 | R-6 | |
| 5KP8.0A | 5KP8.0CA | 8.0 | 8.89 | 9.83 | 5 | 150 | 13.60 | 368.00 | 5000 | R-6 | |
| 5KP8.5A | 5KP8.5CA | 8.5 | 9.44 | 10.40 | 5 | 50 | 14.40 | 347.00 | 5000 | R-6 | |
| 5KP9.0A | 5KP9.0CA | 9.0 | 10.00 | 11.10 | 5 | 20 | 15.40 | 321.00 | 5000 | R-6 | |
| 5KP10A | 5KP10CA | 10.0 | 11.10 | 12.30 | 5 | 15 | 17.00 | 294.00 | 5000 | R-6 | |
| 5KP11A | 5KP11CA | 11.0 | 12.20 | 13.50 | 5 | 10 | 18.20 | 275.00 | 5000 | R-6 | |
| 5KP12A | 5KP12CA | 12.0 | 13.30 | 14.70 | 5 | 5 | 19.90 | 251.00 | 5000 | R-6 | |
| 5KP13A | 5KP13CA | 13.0 | 14.40 | 15.90 | 5 | 2 | 21.50 | 233.00 | 5000 | R-6 | |
| 5KP14A | 5KP14CA | 14.0 | 15.60 | 17.20 | 5 | 2 | 23.20 | 216.00 | 5000 | R-6 | |
| 5KP15A | 5KP15CA | 15.0 | 16.70 | 18.50 | 5 | 2 | 24.40 | 205.00 | 5000 | R-6 | |
| 5KP16A | 5KP16CA | 16.0 | 17.80 | 19.70 | 5 | 2 | 26.00 | 192.00 | 5000 | R-6 | |
| 5KP17A | 5KP17CA | 17.0 | 18.90 | 20.90 | 5 | 2 | 27.60 | 181.00 | 5000 | R-6 | |
| 5KP18A | 5KP18CA | 18.0 | 20.00 | 22.10 | 5 | 2 | 29.20 | 171.00 | 5000 | R-6 | |
| 5KP20A | 5KP20CA | 20.0 | 22.20 | 24.50 | 5 | 2 | 32.40 | 154.00 | 5000 | R-6 | |
| 5KP22A | 5KP22CA | 22.0 | 24.40 | 26.90 | 5 | 2 | 35.50 | 141.00 | 5000 | R-6 | |
| 5KP24A | 5KP24CA | 24.0 | 26.70 | 29.50 | 5 | 2 | 38.90 | 129.00 | 5000 | R-6 | |
| 5KP26A | 5KP26CA | 26.0 | 28.90 | 31.90 | 5 | 2 | 42.10 | 119.00 | 5000 | R-6 | |
| 5KP28A | 5KP28CA | 28.0 | 31.10 | 35.80 | 5 | 2 | 45.40 | 110.00 | 5000 | R-6 | |
| 5KP30A | 5KP30CA | 30.0 | 33.30 | 36.80 | 5 | 2 | 48.40 | 103.00 | 5000 | R-6 | |
| 5KP33A | 5KP33CA | 33.0 | 36.70 | 40.20 | 5 | 2 | 53.30 | 98.80 | 5000 | R-6 | |
| 5KP36A | 5KP36CA | 36.0 | 40.00 | 44.20 | 5 | 2 | 58.10 | 86.10 | 5000 | R-6 | |
| 5KP40A | 5KP40CA | 40.0 | 44.40 | 49.10 | 5 | 2 | 64.50 | 77.50 | 5000 | R-6 | |
| 5KP43A | 5KP43CA | 43.0 | 47.80 | 52.80 | 5 | 2 | 69.40 | 72.00 | 5000 | R-6 | |
| 5KP45A | 5KP45CA | 45.0 | 50.00 | 55.30 | 5 | 2 | 72.70 | 68.80 | 5000 | R-6 | |
| 5KP48A | 5KP48CA | 48.0 | 53.30 | 58.90 | 5 | 2 | 77.40 | 64.40 | 5000 | R-6 | |
| 5KP51A | 5KP51CA | 51.0 | 56.70 | 62.70 | 5 | 2 | 82.40 | 60.70 | 5000 | R-6 | |
| 5KP54A | 5KP54CA | 54.0 | 60.00 | 66.30 | 5 | 2 | 87.10 | 57.40 | 5000 | R-6 | |
| 5KP58A | 5KP58CA | 58.0 | 64.40 | 71.20 | 5 | 2 | 94.00 | 53.40 | 5000 | R-6 | |
| 5KP60A | 5KP60CA | 60.0 | 66.70 | 73.50 | 5 | 2 | 97.00 | 51.70 | 5000 | R-6 | |
| 5KP64A | 5KP64CA | 64.0 | 71.10 | 78.60 | 5 | 2 | 103.00 | 48.50 | 5000 | R-6 | |
| 5KP70A | 5KP70CA | 70.0 | 77.80 | 86.00 | 5 | 2 | 113.00 | 44.20 | 5000 | R-6 | |
| 5KP75A | 5KP75CA | 75.0 | 83.30 | 92.10 | 5 | 2 | 121.00 | 41.30 | 5000 | R-6 | |
| 5KP78A | 5KP78CA | 78.0 | 86.70 | 95.80 | 5 | 2 | 126.00 | 39.70 | 5000 | R-6 | |
| 5KP85A | 5KP85CA | 85.0 | 94.40 | 104.00 | 5 | 2 | 137.00 | 36.50 | 5000 | R-6 | |
| 5KP90A | 5KP90CA | 90.0 | 100.00 | 111.00 | 5 | 2 | 146.00 | 34.20 | 5000 | R-6 | |
| 5KP100A | 5KP100CA | 100.0 | 111.00 | 123.00 | 5 | 2 | 162.00 | 30.90 | 5000 | R-6 | |
| 5KP110A | 5KP110CA | 110.0 | 122.00 | 135.00 | 5 | 2 | 177.00 | 28.20 | 5000 | R-6 | |
| 5KP120A | 5KP120CA | 120.0 | 133.00 | 147.00 | 5 | 2 | 193.00 | 25.90 | 5000 | R-6 | |
| 5KP130A | 5KP130CA | 130.0 | 144.00 | 159.00 | 5 | 2 | 209.00 | 23.90 | 5000 | R-6 | |
| 5KP150A | 5KP150CA | 150.0 | 167.00 | 185.00 | 5 | 2 | 243.00 | 20.60 | 5000 | R-6 | |
| 5KP160A | 5KP160CA | 160.0 | 178.00 | 197.00 | 5 | 2 | 259.00 | 19.30 | 5000 | R-6 | |
| 5KP170A | 5KP170CA | 170.0 | 189.00 | 209.00 | 5 | 2 | 275.00 | 18.20 | 5000 | R-6 | |
| 5KP188A | 5KP188CA | 188.0 | 209.00 | 231.00 | 5 | 2 | 328.00 | 15.20 | 5000 | R-6 | |
| 15KP17A | 15KP17CA | 17.0 | 18.90 | 20.90 | 50 | 5000 | 29.30 | 512.00 | 15000 | R-6 | |
| 15KP18A | 15KP18CA | 18.0 | 20.00 | 22.10 | 50 | 5000 | 30.90 | 485.00 | 15000 | R-6 | |
| 15KP20A | 15KP20CA | 20.0 | 22.20 | 24.50 | 20 | 1500 | 34.30 | 437.00 | 15000 | R-6 | |
| 15KP22A | 15KP22CA | 22.0 | 24.40 | 26.90 | 10 | 500 | 37.10 | 404.00 | 15000 | R-6 | |
| 15KP24A | 15KP24CA | 24.0 | 26.70 | 29.50 | 5 | 150 | 40.50 | 369.00 | 15000 | R-6 | |
| 15KP26A | 15KP26CA | 26.0 | 28.90 | 31.90 | 5 | 50 | 44.00 | 347.00 | 15000 | R-6 | |
| 15KP28A | 15KP28CA | 28.0 | 31.10 | 35.80 | 5 | 25 | 47.50 | 316.00 | 15000 | R-6 | |
| 15KP30A | 15KP30CA | 30.0 | 33.30 | 36.80 | 5 | 15 | 50.70 | 296.00 | 15000 | R-6 | |
| 15KP33A | 15KP33CA | 33.0 | 36.70 | 40.20 | 5 | 10 | 54.80 | 274.00 | 15000 | R-6 | |
| 15KP36A | 15KP36CA | 36.0 | 40.00 | 44.20 | 5 | 10 | 59.70 | 251.00 | 15000 | R-6 | |
| 15KP40A | 15KP40CA | 40.0 | 44.40 | 49.10 | 5 | 10 | 65.80 | 228.00 | 15000 | R-6 | |
| 15KP43A | 15KP43CA | 43.0 | 47.80 | 52.80 | 5 | 10 | 69.70 | 215.00 | 15000 | R-6 | |
| 15KP45A | 15KP45CA | 45.0 | 50.00 | 55.30 | 5 | 10 | 73.00 | 205.00 | 15000 | R-6 | |
| 15KP48A | 15KP48CA | 48.0 | 53.30 | 58.90 | 5 | 10 | 77.70 | 193.00 | 15000 | R-6 | |
| 15KP51A | 15KP51CA | 51.0 | 56.70 | 62.70 | 5 | 10 | 82.80 | 181.00 | 15000 | R-6 | |
| 15KP54A | 15KP54CA | 54.0 | 60.00 | 66.30 | 5 | 10 | 87.50 | 171.00 | 15000 | R-6 | |
| 15KP58A | 15KP58CA | 58.0 | 64.40 | 71.20 | 5 | 10 | 94.00 | 160.00 | 15000 | R-6 | |
| 15KP60A | 15KP60CA | 60.0 | 66.70 | 73.50 | 5 | 10 | 97.30 | 154.00 | 15000 | R-6 | |
| 15KP64A | 15KP64CA | 64.0 | 71.10 | 78.60 | 5 | 10 | 104.00 | 144.00 | 15000 | R-6 | |
| 15KP70A | 15KP70CA | 70.0 | 77.80 | 86.00 | 5 | 10 | 114.00 | 132.00 | 15000 | R-6 | |
| 15KP75A | 15KP75CA | 75.0 | 83.30 | 92.10 | 5 | 10 | 122.00 | 123.00 | 15000 | R-6 | |
| 15KP78A | 15KP78CA | 78.0 | 86.70 | 95.80 | 5 | 10 | 126.00 | 119.00 | 15000 | R-6 | |
| 15KP85A | 15KP85CA | 85.0 | 94.40 | 104.00 | 5 | 10 | 137.00 | 109.00 | 15000 | R-6 | |
| 15KP90A | 15KP90CA | 90.0 | 100.00 | 111.00 | 5 | 10 | 146.00 | 103.00 | 15000 | R-6 | |
| 15KP100A | 15KP100CA | 100.0 | 111.00 | 123.00 | 5 | 10 | 162.00 | 93.00 | 15000 | R-6 | |
| 15KP110A | 15KP110CA | 110.0 | 122.00 | 135.00 | 5 | 10 | 177.00 | 84.00 | 15000 | R-6 | |
| 15KP120A | 15KP120CA | 120.0 | 133.00 | 147.00 | 5 | 10 | 193.00 | 78.00 | 15000 | R-6 | |
| 15KP130A | 15KP130CA | 130.0 | 144.00 | 159.00 | 5 | 10 | 209.00 | 72.00 | 15000 | R-6 | |
| 15KP150A | 15KP150CA | 150.0 | 167.00 | 185.00 | 5 | 10 | 243.00 | 62.00 | 15000 | R-6 | |
| 15KP160A | 15KP160CA | 160.0 | 178.00 | 197.00 | 5 | 10 | 259.00 | 58.00 | 15000 | R-6 | |
| 15KP170A | 15KP170CA | 170.0 | 189.00 | 209.00 | 5 | 10 | 275.00 | 55.00 | 15000 | R-6 | |
| 15KP180A | 15KP180CA | 180.0 | 200.00 | 221.00 | 5 | 10 | 291.00 | 52.00 | 15000 | R-6 | |
| 15KP200A | 15KP200CA | 200.0 | 222.00 | 246.00 | 5 | 10 | 322.00 | 47.00 | 15000 | R-6 | |
| 15KP220A | 15KP220CA | 220.0 | 245.00 | 270.00 | 5 | 10 | 356.00 | 42.00 | 15000 | R-6 | |
| 15KP240A | 15KP240CA | 240.0 | 267.00 | 295.00 | 5 | 10 | 388.00 | 39.00 | 15000 | R-6 | |
| 15KP260A | 15KP260CA | 260.0 | 289.00 | 319.00 | 5 | 10 | 419.00 | 36.00 | 15000 | R-6 | |
| 15KP280A | 15KP280CA | 280.0 | 311.00 | 343.00 | 5 | 10 | 452.00 | 33.00 | 15000 | R-6 | |
Copyright © Wuxi Xuyang Electronics Co., Ltd. All Rights Reserved Powered by
苏ICP备05067640号-1
