Features
1.High reliability
2.Low reverse current and low forward voltage
Applications
Low current rectification and high speed switching
Construction
Silicon epitaxial planar
| Type | VFM | IRM | Package | Download | |||
 VRRM | |||||||
| (I=IRM) | VFM | I(AV) | IRM | VR | |||
| V | V | mA | μA | V | |||
| 1N60 | 40 | 1 | 30 | 0.1 | 15 | DO-35 | |
| 1N60P | 45 | 1 | 200 | 0.5 | 15 | DO-35 | |
| BAT85 | 30 | 0.8 | 100 | 2 | 25 | DO-35 | |
| BAT86 | 50 | 0.9 | 100 | 5 | 40 | DO-35 | |
| BAT42 | 30 | 1 | 200 | 0.5 | 25 | DO-35 | |
| BAT43 | 30 | 1 | 200 | 0.5 | 25 | DO-35 | |
| BAT48 | 40 | 0.75 | 200 | 25 | 40 | DO-35 | |
| SD103A | 40 | 0.6 | 200 | 5 | 30 | DO-35 | |
| SD103B | 30 | 0.6 | 200 | 5 | 20 | DO-35 | |
| SD103C | 20 | 0.6 | 200 | 5 | 10 | DO-35 | |
| RB721Q-40 | 40 | 0.37 | 1 | 0.5 | 25 | DO-35 | |
| RB441Q-40 | 40 | 0.55 | 100 | 100 | 40 | DO-35 | |
| MA700 | 15 | 0.4 | 10 | 0.1 | 15 | DO-35 | |
| MA700A | 30 | 0.4 | 1 | 0.15 | 30 | DO-35 | |
| LL60 | 40 | 1 | 30 | 0.1 | 15 | SOD-80 | |
| LL60P | 45 | 1 | 200 | 0.5 | 15 | SOD-80 | |
| BAS85 | 30 | 0.8 | 100 | 2 | 25 | SOD-80 | |
| BAS86 | 50 | 0.9 | 100 | 5 | 40 | SOD-80 | |
| BAS48 | 40 | 0.75 | 200 | 25 | 40 | SOD-80 | |
| LL42 | 30 | 1 | 200 | 0.5 | 25 | SOD-80 | |
| LL43 | 30 | 1 | 200 | 0.5 | 25 | SOD-80 | |
| MCL103A | 40 | 0.6 | 200 | 5 | 30 | micromelf | |
| MCL103B | 30 | 0.6 | 200 | 5 | 20 | micromelf | |
| MCL103C | 20 | 0.6 | 200 | 5 | 10 | micromelf | |
| LL103A | 40 | 0.6 | 200 | 5 | 30 | SOD-80 | |
| LL103B | 30 | 0.6 | 200 | 5 | 20 | SOD-80 | |
| LL103C | 20 | 0.6 | 200 | 5 | 10 | SOD-80 | |
| LL700 | 15 | 0.4 | 10 | 0.1 | 15 | SOD-80 | |
| LL700A | 30 | 0.4 | 1 | 0.15 | 30 | SOD-80 | |
